Product Description
The PANDUIT FZTYP7EL2SAM030 is an OM4 multimode 12-fiber trunk cable terminated with PanMPO connectors on both ends in a female-to-female configuration. Rated OFNP (optical fiber nonconductive plenum), this assembly meets plenum-space requirements and is designed for high-density structured cabling installations. The OM4 fiber grade supports high-bandwidth applications at extended reach, making this trunk suitable for data center backbone and campus interconnect runs. Installation is handled by licensed low-voltage or structured cabling technicians.
This trunk cable assembly is used in high-density fiber backbone applications, primarily in data centers, enterprise wiring closets, and structured cabling infrastructures where space-optimized MPO-based connectivity is required. The OFNP plenum rating qualifies it for installation in air-handling spaces and plenum ceiling pathways without the need for conduit in many jurisdictions. The PanMPO interface aligns with PANDUIT high-density fiber systems and cassette-based patching architectures.
Key Features
- OM4 multimode fiber supports high-bandwidth, high-speed network applications
- 12-fiber count in a single trunk assembly for high-density routing
- OFNP plenum-rated jacket approved for air-handling and plenum space installation
- PanMPO connectors on both ends for compatibility with PANDUIT high-density fiber systems
- Female-to-female (F/L) connector configuration for direct cassette or adapter panel termination
- Factory-terminated trunk assembly reduces field termination time and labor
Compatibility
Designed as an OEM-style replacement or direct-install trunk assembly for use in PANDUIT PanMPO high-density fiber patching systems. Consult PANDUIT system documentation for specific cassette, adapter panel, and enclosure compatibility.
Installation Notes
Installation should be performed by a qualified low-voltage or structured cabling technician following TIA-568 and applicable local codes. Power down active equipment before mating or un-mating fiber connectors to avoid damage to optical transceivers. Observe minimum bend radius requirements throughout the cable route to prevent signal degradation. Do not exceed rated tensile load during pulling and secure the assembly with appropriate fiber-safe fasteners.
Technical Specifications
- Fiber Type: OM4 Multimode
- Fiber Count: 12
- Jacket Rating: OFNP (Optical Fiber Nonconductive Plenum)
- Connector Type: PanMPO
- Connector Configuration: Female to Female (F/L)
- Unit of Measure: EA (Each)
- Quantity per Unit: 1
Standard Information
- Brand: PANDUIT
- Manufacturer Part Number: FZTYP7EL2SAM030
